Highlite Showtec Spectral Q4 MkII

Highlite Showtec Spectral M1500 Zoom Q4 MkIII

by Highlite Showtec
SKU 43549
$1,530.00 ex. GST - $1,530.00 ex. GST
$1,530.00 ex. GST
$1,530.00 ex. GST - $1,530.00 ex. GST
$1,530.00 ex. GST

All Prices Shown are Excluding GST.

  • Electronic Zoom: 8-40° (pin spot to wash)
  • 7 x 20W RGBW 4-in-1 Osram
  • Convection cooling
  • 2 controllable sections (centre and surrounding spots)
  • IP65 (dust and water resistant, fit for outdoor use)
  • Dimmer and strobe function
The Showtec Spectral M1500 Zoom Q4 MKIII is a 7x 20 watt RGBW LED spot to wash Parcan, with a wide 8°–40° motorised zoom range and high CRI, suitable for in- and outdoor applications. Each function, including its 2-section LED control, 0–100 % dimmer, 0–20 Hz strobe and colour mixing engine, is controllable via DMX and Master/Slave in either Manual and Auto run mode. The compact and lightweight 7 kg design, with IP65 rating and -10~40 °C operating temperature range, makes the Spectral M1500 Zoom MKIII fit for almost any environment.


Specifications

Source

Light Source Type  LED
Light Source Quantity 7
Light Source Power 20 W
LED Colour Type RGBW
Refresh Rate 1200 Hz
Illuminance @ 2 m 17936 lx
Illuminance @ 3 m 7972 lx
Illuminance @ 5 m 2870 lx
Luminous Flux (Total) 2696 lm
Luminous Flux (Red) 532 lm
Luminous Flux (Green) 1028 lm
Luminous Flux (Blue) 341 lm
Luminous Flux (White) 1246 lm
CRI 85



Optical

Beam Angle Min. (Circular)  8°
Beam Angle Max. (Circular) 40°
Zoom Type Motorised
Zoom Minimum 8°
Zoom Maximum 40°

Control and Programming

Control Mode Auto, DMX, Manual, Master Slave
DMX Channels 3, 4, 5, 6, 7, 12, 17, 25
Protocols DMX, RDM
Display 4-segment, LED

Dynamic Effects

Dimmer 0-100 %
Strobe 0-20 Hz

Electrical Specifications and Connections

Power Supply 100-240 VAC 50-60 Hz
Power Consumption 128 W
Power Connector In powerCON TRUE1
Power Connector Out powerCON TRUE1
DMX Connector Dedicated 3P IP65 In/Out
DMX Connector In Dedicated 3P IP65
DMX Connector Out Dedicated 3P IP65
Cable Length 1.5 m

Mechanical Specifications

Length (mm) 255 mm
Width (mm) 225 mm
Height (mm) 360 mm
Weight 7 kg
IP Rating IP65
Housing Aluminium die-cast
Colour Black

Product Properties

Cooling  Convection

Rigging

Mounting Options  Clamp, Surface
Safety Attachment  Yes

Thermal Specifications

Maximum Ambient Temperature  40 °C
Minimum Operating Temperature  -10 °C

Included Items

Included Cables powerCON TRUE1 cable
Included Accessories User Manual
Included Rigging Bracket

Order Code : 43549 (Supersedes 43543 & 43547)
