ARRI EB6/9 Ballast 50/60/75Hz VEAM, ALF,DMX,CCL, blue standard housing

ARRI EB6/9 Ballast 50/60/75Hz VEAM, ALF,DMX,CCL, blue standard housing

by ARRI
SKU L2.76181.0
Request a quote

All Prices Shown are Excluding GST.

ARRI EB 6/9 Ballast

The EB 6/9 kW is available in DMX and high speed versions. Like other recent ballasts from ARRI, it features CCL (Compensation of Cable Loss) technology and the power-saving ALF (Active Line Filter). The EB 6/9 kW uses the housing of the current EB 6000 Baby and is compatible with 6K head-to-ballast cables. The EB 6/9 automatically detects not only the 9,000W and 6,000W lamp but also 6k and 9K lampheads.

Features:

  • Size of EB 6000 Baby
  • Can be also used for 6K lampheads
  • Automatic detection of 6K and 9K lampheads
  • Automatic detection of 6,000 W and 9,000 W lamps in 9K lampheads
  • CCL (Compensation of Cable Losses)
  • ALF (Active Line Filter)
  • DMX – version of EB 6/9 kW (On/Off; dimming)
  • High Speed – version of EB 6/9 kW (1,000 Hz; adjustable in range 900–1200 Hz / 75 Hz / 50 Hz)
